Imeca Search Key
BMS 3200. IR

SLIDING PANEL SAW. 1 PHASE . 5HP 220V

Be the first to review this product
$16,902.55

In Stock This product is available.

Shipping Available This product is available for delivery.

Add to Wish List Compare
SLIDING PANEL SAW. 1 PHASE . 5HP 220V is available to buy in increments of 1
Introducing the New BMS.3200.IR 40-year Edition. The BMS series is one of Maksiwa’s top seller sliders that has been completely redesigned from the ground up with improved construction and materials. The new design is more ergonomic and features a more powerful 1HP scoring motor, adjustable leveling feet, dual blade covers, integrated dust collection exhaust on a swing-away arm, and new soft touch buttons and control panel. All these improvements come at the same unbeatable price as before!
Color: Not Informed
Brand: MAKSIWA
Marketing Copy: Introducing the New BMS.3200.IR 40-year Edition. The BMS series is one of Maksiwa’s top seller sliders that has been completely redesigned from the ground up with improved construction and materials. The new design is more ergonomic and features a more powerful 1HP scoring motor, adjustable leveling feet, dual blade covers, integrated dust collection exhaust on a swing-away arm, and new soft touch buttons and control panel. All these improvements come at the same unbeatable price as before!
Sell Without Stock: Yes
Imeca Product: No
Main Motor5 HP/ 4000 RPM 3.7 Kw
Max Blade Diameter12" | 305mm
Main Blade Arbor1 3/16" | 30mm
Main Blade Max cutting Height at 90°3 1/2 " | 90mm
Main Blade Cutting Height at 45°2 1/8" | 53mm
Scoring Motor1 HP / 8000 RPM .74Kw
Scoring Motor Blade4 3/4" | 12mm
Scoring Blade Arbor3/4" | 20mm
Scoring Blade TypeConical
Max Ripping Capacity51" | 1295mm
Crosscut Capacity126" | 3200 mm
Crosscut Fence Capacity Closed/Open74 3/4" / 108" | 1899 MM / 2743 mm
Machine Working Dimensions (LxWxH)126" x 137" x 52" | 3200 x 3480 x 1321mm
Cast Iron Table Dimension (LxWxH)31 1/2" x 21" x 34 3/4" | 800 X 553 X 883 mm
Sliding Table Dimension (LxW)126" x 14 3/4" | 3200 x 375 mm
Dust Collection Port (2)4"
Minimum Dust Collection Requirements1000 CFM | 28m/min
Electrical Specs1 Phase 220V 22 Amps 60 Hz

3 Phase 220V 11 Amps 60 Hz

Main Body Crate Dimensions (LxWxH)88" x 48" x 43" | 2245 x 1130 x 1090 mm
Main Body Crate Weight Net/Gross1102/1257 LBS | 500/ 570 KGS
Sliding Table Crate Dimensions (LxWxH)140" x 19" x 8 1/2" | 3556 x 483 x 216 mm
Sliding Table Crate Weight Net/Gross227/282 LBS | 103/128 KGS
